Monday, January 26, 2015

Audio Development Co Filament Transformers - What to do?

My good friend Chris dropped these by my house a while back. Not just one very nice filament transformer but two. I went through the combinations of tubes I could light up with it and I got very distracted quickly...
6.3V   3.1A
6.3V   2.5A
6.3V   .45A
6.3V   .30A
5.0V   2.0A
5.0V   2.0A

Friday, January 23, 2015

Retro Hi-Fi Girl Friday

Not retro but I don't care. Look at that clean work. Superb!

Wednesday, January 21, 2015

Western Electric - Quality Counts

It has been a while since I posted a Western Electric ad. Here is one feature a small segment of their products. Good stuff.. The 713 driver was used on early Klipschorns with the K5 horn. That would have been a two way system.

Monday, January 19, 2015

How to Build A Universal Audio Amplifier And Power Supply - Radio News 1930

Another great Radio News article this one on building a universal power supply.




Sunday, January 18, 2015

Electro Harmonix 300B Tubes Being Made - Russian Factory

Great video of the Expo-Pul factory producing 300B tubes. Who is Expo-Pul? They make tubes for Sovtek, Electro-Harmonix, Tungsol, Svetlana, Mullard and others.


They had a bit of trouble a few years ago. Here are a couple interesting stories regarding the factories history. Articles may be a bit older but a good bit of recent history. They picked on the wrong guy.




Friday, January 16, 2015

Wednesday, January 14, 2015

CBias Resistors Their Placement and Value Radio News 1930

Great lesson from 1930 on selection and importance of bias resistors.


Monday, January 12, 2015

Vintage General Radio 1551 SPL Meter

Want to measure in style then you need one of these General Radio 1551 SPL Meters. The radio shack may be light weight but it ain't got no style.
None
Nada
Nyet
forget about it
Wow!


Sunday, January 11, 2015

TALKING HEADS LIVE 1980

Talking Heads was one of those bands that I love from first listen. This concert is superb I recommend chilling out and watching the entire show. At this point they had been together since 1975.

From the Byron Dept Of Internet Research

Friday, January 9, 2015

Wednesday, January 7, 2015

What Makes An Amplifier Sound Good Part 2

Early 60's article by Ken Gilmore on what makes an amplifier sound good.




Monday, January 5, 2015

What Makes An Amplifier Sound Good Part 1

Early 60's article by Ken Gilmore on what makes an amplifier sound good.





Saturday, January 3, 2015

Hellllo 2015



Ran speaker wire in wall in my music room so I could move my equipment from between the speakers.

2015 is going to rock!

Goals
Complete 2A3/45 stereo amp by the end of January.
Build WE421A stereo amp.
Build modern Brook 12A clone.
 Veneer my Garrard 301 Plinth.
Veneer Jubilee speakers.
At least get a schematic complete for line level crossover for Jubilee system.



I just thought this was funny as hell........
Thanks to Chris, Kenny, Jeffrey, Dave, Joe, Tim, Jim, Terry, and JC for the encouragement and help this year. Wouldn't be this far without you.

Friday, January 2, 2015

Thursday, January 1, 2015

Installation Of The Month 1961

This guy put together a killer system in 61..

Monday, December 29, 2014

Chinese Military Horn

Weaponized horns... This is one of two. I understand they were blasting Enoch Light.




Sunday, December 28, 2014

Garrard 301 BBC Hammertone Audio Grail Restorations

Audio Grail 301 restoration. Good info.

Friday, December 26, 2014

Wednesday, December 24, 2014

Merry Freaky Christmas

Christmas Songs From Some Folks You May Know..... Ho Ho..... HO!
I'm burnt out on the traditional xmas tunes.....

RUN DMC

Ertha Kitt

I prefer Lyman's version but she looks too much like Betty Page.
Mele Kalikimaka

Tom Waits

Sex Pistols

Ramones

Beatles 1968 Christmas Record
Usually sent to fan club members.

Joseph Spence
One of my faves uploaded this years ago.

James Brown

Akim & Teddy

 Christmas ????????????????



Tuesday, December 23, 2014

1927 Raleigh Mullard Tube Amp

I love the wiring and look of this 1927 Mullard amplifier.
Beautiful!!!!
Early radios produced little power, so extra amplifiers were often added. There was no industry producing them on a large scale, but they could always be built at home, like this magnificent creation of the late 1920s made by PFW Bush. Big amplifiers need plenty of raw power to work on, and this one had a hefty power supply. It also used two valves to drive the loudspeaker, one pushing, the other pulling. A similar arrangement is still used in modern amplifiers. - See more at: http://www.sciencemuseum.org.uk/online_science/explore_our_collections/objects/index/smxg-35205#na
